One Function Manual Bed – Technical Specification
| Item | Specification |
| Product Name | One Function Manual Hospital Bed |
| Type | Single Crank Manual Hospital Bed |
| Overall Dimensions | Approx L-2034 x W-890 x H-915 mm. |
| Mattress Platform | 3 Inch Foam Mattress |
| Frame Material | Heavy-duty Mild Steel (MS) with epoxy powder-coated finish |
| Backrest Adjustment | Manual crank-operated backrest adjustment |
| Backrest Angle | 0°–85° (Approx.) |
| Adjustment Mechanism | Smooth manual crank system with foldable ABS handle |
| Head & Foot Boards | Detachable high-strength ABS molded head and foot panels |
| Side Rails | Foldable aluminum alloy side rails with safety locking system |
| Bed Frame | Reinforced MS rectangular steel frame for high strength and durability |
| Castors | Four heavy-duty 5’’ swivel castors with Individual locking brakes |
| IV Pole Sockets | Four IV pole mounting sockets at each corner |
| Load Capacity | Minimum 180 kg Safe Working Load |
| Warranty | 1 year service |
STRANDED ACCESSORIES :
- Mattress
- 2″ Two-part foam mattress with washable rexene.
One adjustable IV pole is provided with the bed.
