Double Dome LED Operation Theatre (OT) Light – Technical Specification
| Item | Specification |
| Product Name | Double Dome LED Operation Theatre (OT) Light |
| Type | Ceiling Mounted Double Dome Shadowless LED Surgical Light |
| Configuration | Dual dome surgical light with ceiling suspension system |
| Light Source | High-efficiency white LED modules |
| Number of Domes | 2 (Two) independently adjustable light heads |
| Illumination Intensity | 40,000–160,000 Lux (each dome), adjustable |
| Color Temperature | 3,500–5,500 K, adjustable |
| Color Rendering Index (CRI) | ≥95 Ra |
| Light Field Diameter | 120–300 mm, adjustable |
| Depth of Illumination | ≥1,000 mm |
| LED Service Life | Minimum 50,000 hours |
| Brightness Control | Touch or membrane control panel with continuous dimming (10–100%) |
| Focus Adjustment | Manual adjustable focus |
| Shadow Control | Advanced shadow reduction technology for uniform illumination |
| Heat Radiation | Minimal infrared (IR) and ultraviolet (UV) radiation for reduced heat generation |
| Suspension System | Ceiling-mounted articulated suspension arm with 360° rotation |
| Light Head Movement | Smooth multi-axis positioning with ergonomic sterile handles |
| Sterilizable Handles | Removable and autoclavable handles for infection control |
| Control Panel | Integrated digital control panel on each light head |
| Power Supply | 220–240 VAC, 50/60 Hz |
| Power Consumption | Low power consumption, energy-efficient LED technology |
| Protection Class | IP-rated protection against dust and liquid ingress |
| Emergency Backup | Compatible with hospital UPS |
